Product Specifications These product specifications meet or exceed GRI GM13.
|
Tested Property |
Test Method |
Frequency |
Minimum Average Value |
|||||||
|
Thickness, (minimum average) mm (mil) |
ASTM D 5199 |
every roll |
0.3 (12) |
0.5 (20) |
0.75 (30) |
1.0 (40) |
1.5 (60) |
2.0 (80) |
2.5 (100) |
3.0 (120) |
|
Lowest individual reading, mm (mil) |
|
|
0.27 (10.8) |
0.45 (18) |
0.68 (27) |
0.9 (36) |
1.35(54) |
1.8 (72) |
2.25 (90) |
2.7 (108) |
|
Density, g/cm3 |
ASTM D 1505 |
every 5th roll |
0.94 |
0.94 |
0.94 |
0.94 |
0.94 |
0.94 |
0.94 |
0.94 |
|
Tensile Properties (each direction) Strength at Break, N/mm-width (lb/in) Strength at Yield, N/mm-width (lb/in) Elongation at Break, % Elongation at Yield, % |
ASTM D 6693, Type IV Dumbell, 2 ipm
G.L. 51 mm (2.0 in) G.L. 33 mm (1.3 in) |
every 5th roll |
8 (46) 5 (29) 600 13 |
14 (80) 8 (46) 700 13 |
21 (120) 11 (63) 700 13 |
28 (160) 15 (86) 700 13 |
43 (246) 23 (131) 700 13 |
57 (325) 30 (171) 700 13 |
71 (405) 38 (217) 700 13 |
85 (485) 45 (257) 700 13 |
|
Tear Resistance, N (lb) |
ASTM D 1004 |
every 5th roll |
40 (9) |
65 (15) |
93 (21) |
125 (28) |
187 (42) |
249 (56) |
311 (70) |
373 (84) |
|
Puncture Resistance, N (lb) |
ASTM D 4833 |
every 5th roll |
105(24) |
176(40) |
263(59) |
352(79) |
530(119) |
703(158) |
881(198) |
1,059 (238) |
|
Carbon Black Content, % |
ASTM D 1603 / D 4218 |
every 5th roll |
2.0-3.0 |
2.0-3.0 |
2.0-3.0 |
2.0-3.0 |
2.0-3.0 |
2.0-3.0 |
2.0-3.0 |
2.0-3.0 |
|
Carbon Black Dispersion |
ASTM D 5596 |
every 5th roll |
Note (1) |
Note(1) |
Note (1) |
Note(1) |
Note(1) |
Note(1) |
Note (1) |
Note (1) |
|
Notched Constant Tensile Load, hrs |
ASTM D 5397, Appendix |
90,000 kg |
400 |
400 |
400 |
400 |
400 |
400 |
400 |
400 |
|
Oxidative Induction Time, minutes |
ASTM D 3895, 200° C; O2, 1 atm |
90,000 kg |
>100 |
>100 |
>100 |
>100 |
>100 |
>100 |
>100 |
>100 |
|
TYPICAL ROLL DIMENSIONS |
|
|
|
|||||||
|
Roll Length (approximate), m (ft) |
200 (656) |
420 (1,378) |
280 (918) |
210 (689) |
140 (459) |
105 (344) |
85 (279) |
70 (230) |
||
|
Roll Width, m (ft) |
7.1 (23.3) |
7.1 (23.3) |
7.0 (23) |
7.0 (23) |
7.0 (23) |
7.0 (23) |
7.0 (23) |
7.0 (23) |
||
|
Roll Area, m2 (ft2) |
1,420 (15,284) |
2,982 (32,107) |
1,960 (21,114) |
1,470 (15,847) |
980 (10,557) |
735 (7,912) |
595 (6,417) |
490 (5,290) |
||
|
40’ Standard Container, roll |
35 |
16 |
16 |
16 |
16 |
16 |
16 |
16 |
||
NOTES:
